Tidal II Connect 18in Wall, 48in, SS, LED, ACT
Tidal II Connect 18in Wall, 48in, SS, LED, ACT
Call for Our Best Price
We might not be able to fulfill your order for the quantity requested
Dimensions
Width: 47.875
Height: 18
Depth: 24
Color
Also Comes In
Stainless Steel
Stainless Steel
Related Items...
Features
- Airflow Control Technology or ACT is an exclusive technology that gives installers the ability to set the maximum CFM levels to meet local code requirements.
- LumiLight LED lights are eco-friendly and built to last with a lifetime of more than 25,000 hours.
- The Zephyr Connect app allows customers to remotely control their range hoods from anywhere using a mobile device.
- High-airflow baffle filters that are dishwasher safe and ensure a lifetime of exceptional performance.
- The CleanAir Function powers the hood on every four hours for 10 minutes to refresh the cooking area.
- This hood has the ability to vent either out the top or out the back.
- Ductless recirculating kit used when venting air outside your home is not possible. Smoke and odors pass through charcoal filters allowing purified air to be reintroduced into the kitchen.
Product Description
Designed for the ultimate pro-style kitchen, Tidal II wall hood features optional dual 1300-CFM PowerWave™ blowers, Zephyr Connect capabilities, and professional baffle filters. The next wave of the future, Tidal II is equipped with LumiLight LED Lighting and 6-Speed Proximity Touch Controls.
Specification
| General | |
| Blower Included | Yes |
| Blower CFM w/ACT | 590, 390, 290 |
| Internal Blower 1 CFM | 700 |
| Internal Blower 1 Min. Sones | 0.8 |
| Internal Blower 1 Max Sones | 6 |
| Internal Blower 2 CFM | 1300 |
| Minimum CFM | 200 |
| Installation Type | Wall |
| For Outdoor Use | No |
| Controls Type | Proximity Touch |
| Blower Speeds | 6 |
| Automatic Delay-Off | Yes |
| Clean Air Function | Yes |
| Lighting Type | LED |
| Lights Quantity | 4 |
| Watts Per Bulb | 6 |
| Lights Levels | 3 |
| Grease Filter Type | Pro baffle |
| Duct Discharge | Vertical or Horizontal |
| Duct Size; Horizontal in. | 8, 3.25 x 10 |
| Duct Size; Vertical in. | 8 |
| Mounting Height Above Cooktop in. | 24 - 36 |
| Voltage | 120 |
| Maximum Amperage | 5 |
| ADA Compliant | Yes, with optional remote |
| Warranty Parts / Labor | 3 / 1 |
| Compatible Appliances | 14000005, PBD-1300B, ZRC-7048C, AK0728, AK1728, MUA008A, MUA010A, Z0F-C002, AK1718 |
| Bluetooth Connected | No |
| Wi-Fi Connected | Yes |
| Remote Included | No |
| Remote Optional | Yes |
| Energy Star Certified | No |
| Alexa & Google Home Compatible | Yes |
| CEC Title 20 Compliant | Yes |
| CEC Title 24 Compliant | Yes |
| Primary Material | Stainless Steel |
| Wattage | 600 |
| Certification | UL |
| Nominal Width in. | 48 |
| Net Width in. | 47.875 |
| Net Depth in. | 24 |
| Net Height in. | 18 |
| Weight lbs. | 76.000 |
| Ceiling Height Minimum | 8 ft. |
| Ceiling Height Maximum | 12 ft. |
| Clean Filter Alert | Yes |
| Duct Type | Vertical |
| Duct Type 2 | Horizontal |
Documentation
From the Manufacturer
Warranty
Extended warranties can save you hundreds, sometimes even thousands of dollars in unexpected repairs. You can contact us, or visit our store for additional details.
Delivery
Let our team co-ordinate professional delivery and installation on your new purchase. Some restrictions may apply.
Disclosures
Proposition 65 Warning for California ResidentsFeatures
